/ Thrust ball bearings

Double Direction Thrust Ball Bearing

1.Product Introduction: With a double-row steel ball + intermediate washer structure, capable of bearing bidirectional axial loads, without the need for additional paired bearings, suitable for bidirectional axial scenarios.
2.Structure Type: Intermediate washer (fixed) + double shaft washers (fitted to the shaft) + double-row steel balls + cage, the intermediate washer has double raceways.
3.Size Range: Inner diameter: 15 - 250mm, outer diameter: 40 - 350mm, height: 15 - 60mm.
4.Material: Shaft washer: GCr15/GCR15SIMN/20Cr2Ni4A, housing washer (intermediate washer): GCr15/GCR15SIMN/20Cr2Ni4A, rolling elements (steel balls): GCr15/GCR15SIMN, cage: stamped steel / brass.
5.Accuracy: Conventional P0/P6 grades, precision models are of P5 grade.
6.Application Fields: Bidirectional positioning of machine tool spindles, printing machinery, textile equipment.
7.Key Inspection Items: Bidirectional axial clearance, consistency of double-row steel balls, parallelism of the intermediate washer.

Send Inquiry

Download

Product Description

Data Sheet

Double Direction Thrust Ball Bearings for Heavy-Duty Industrial Applications | High-Load Capacity, Extreme-Temperature Resistance, Custom Sizes up to φ5000mm

When your machinery faces extreme axial loads, heat, or demanding operational conditions, Double Direction Thrust Ball Bearings provide the robust, bidirectional support you need. Designed to handle axial forces in both directions without requiring paired bearings, our solutions are engineered for reliability in heavy industries like metallurgy, mining, and port machinery. With 30+ years of expertise, LUOYANG INNO BEARING CO., LTD delivers precision-crafted bearings that optimize performance, reduce downtime, and adapt to your unique requirements—whether standard sizes or custom designs up to φ5000mm.

product-750-750

Technical Specifications

Design: Double-row steel balls + intermediate washer for bidirectional axial load support.
Materials: High-purity chromium steel (ISO 683-17 standard), heat-treated for wear resistance.
Load Capacity: Static axial load up to 1,500 kN; dynamic axial load up to 800 kN.
Temperature Range: -30℃ to +150℃ (ceramic-coated options available).
Precision: Grades P0/P6 standard; P5 for high-precision applications.
Sizes: Standard (ID 15mm–250mm) and custom (up to φ5000mm).
Noise Control: ≤35dB for medical and robotics equipment.

Where Our Double Direction Thrust Ball Bearings Excel?

1. Metallurgical Furnace Conveyors

Withstand 500℃ temperatures and heavy axial loads in continuous operations. Our heat-treated steel and aligned raceways prevent deformation under thermal stress.

2. Port Machinery Cranes

Absorb shock loads from dynamic lifting while maintaining alignment. Corrosion-resistant coatings (e.g., carbide plating) protect against saltwater exposure.

3. Mining Crushers

Durable designs combat abrasive wear. Modular cages and hardened steel balls extend lifespan in high-impact environments.

product-1256-742

Customization to Fit Your Needs

Need bearings beyond standard specs? We specialize in:

Oversized Designs: Up to φ5000mm for mega machinery.
Material Upgrades: Stainless steel, ceramic coatings, or specialty alloys.
Performance Tweaks: Adjust raceway geometry for noise reduction or load distribution.
Rapid Prototyping: Receive φ1000mm+ custom prototypes in 15 days.

Quality Assured, Tested to Last

Every Double Direction Thrust Ball Bearing undergoes:

1. Material Traceability: SGS-certified steel suppliers.

2. Rigorous Testing: 100% vibration analysis (<4.5μm), lifespan simulations (10,000+ hours), and axial load stress tests.

3. Certifications: ISO 9001, CE, and industry-specific compliance (e.g., API for mining).

Global Supply Chain, Fast Delivery

48-Hour Dispatch: 1,000+ standard bearings in stock.
Regional Warehouses: EU, NA, and Asia hubs for bulk orders.
Custom Orders: Shipped in 15–20 days post-design approval.

Technical Support You Can Trust

From concept to installation:

Free Engineering Consultations: Optimize bearing selection with CAD simulations.
On-Site Guidance: Ensure proper alignment and load distribution.
IoT Monitoring: Optional real-time health tracking to predict maintenance needs.

Why Partner With Us?

1. 30+ Years of Expertise: Vertical integration from R&D to QC ensures unmatched quality.

2. Proven Cross-Industry Success: Trusted by metallurgy, mining, and medical sectors.

3. End-to-End Support: Dedicated project managers streamline every order.

FAQs

1. How do your bearings handle 500℃ temperatures?

We use heat-treated chromium steel and ceramic coatings to maintain structural integrity under extreme heat.

2. Can you make bearings larger than φ3000mm?

Yes! Our modular production system enables custom designs up to φ5000mm with a 15–20 day lead time.

3. What material innovations improve wear resistance?

High-purity steel, precision grinding, and specialty coatings (e.g., carbide) reduce wear in abrasive conditions.

4. How is P4 precision achieved with low noise?

Advanced grinding techniques and cage designs minimize vibration, ensuring ≤35dB operation.

5. What testing ensures defect-free bearings?

Three-stage QC includes raw material checks, in-process inspections, and 100% final testing.

Contact Us

Need more answers? Contact our team at sales@inno-bearing.com for tailored support.

Optimize your machinery with Double Direction Thrust Ball Bearings built to endure. Email us today for a quote or consultation.

d 65～100mm
Overall Dimensions						Rated Load		Limiting Rotational Speed		Bearing Designation		Minimum Load A	Mounting Dimensions			Weight
d	d1min	D	D1max	H	rnin	Dynamic Load C	Static Load Co	Grease	Oil	Current Model	Original Model	Minimum Load A	da	Da	ramax	Weight
mm						kN		r/min					mm			kg
65	67	115	115	36	1.1	116	228	1600	2200	51313	8313	0.638	95	85	1	1.57
65	68	140	140	56	2	217	428	1000	1500	51413	8413	1.48	110	95	2	4.2
70	72	95	95	18	1	42	119	2400	3400	51114	8114	0.119	85	80	1	0.36
	72	105	105	27	1	73.6	161	1800	2600	51214	8214	0.226	91	84	1	0.81
	72	125	125	40	1.1	148	285	1400	1900	51314	8314	0.756	103	92	1	1.932
	73	150	150	60	2	257	475	950	1400	51414	8414	2.07	118	102	2	5.18
75	77	100	100	19	1	44	130	2200	3200	51115	8115	0.128	90	85	1	0.42
	77	110	110	27	1	74.9	173	1700	2400	51215	8215	0.295	96	89	1	0.86
	77	135	135	44	1.5	163	342	1200	1700	51315	8315	1.04	111	99	1.5	2.7
	78	160	160	65	2	269	532	900	1300	51415	8415	3.05	125	110	2	6.97
80	82	105	105	19	1	48.8	133	2000	3000	51116	8116	0.138	95	90	1	0.43
	82	115	115	28	1	83.8	193	1700	2400	51216	8216	0.324	101	94	1	0.95
	82	140	140	44	1.5	178	342	1200	1700	51316	8316	1.19	116	104	1.5	2.58
	83	170	170	68	2.1	292	589	850	1200	51416	8416	3.726	133	117	2	7.11
85	87	110	110	19	1	49.2	143	2000	3000	51117	8117	0.148	100	95	1	0.46
	88	125	125	31	1	103	238	1600	2200	51217	8217	0.56	109	101	1	1.3
	88	150	150	49	1.5	209	404	1100	1600	51317	8317	1.766	123	111	15	3.7
	88	180	177	72	2.1	318	646	850	1200	51417	8417	4.42	141	124	2	9.5
90	92	120	120	22	1	65.1	181	1800	2600	51118	8118	0.256	108	102	1	0.636
	93	135	135	35	1.1	125	285	1500	2000	51218	8218	0.746	117	108	1	1.77
	93	155	155	50	1.5	221	408	1000	1500	51318M	8318	0.202	129	116	1.5	4.21
	93	190	187	77	2.1	327	713	800	1100	51418	8418	6.09	149	131	2	11.2
100	102	135	135	25	1	85.1	257	1700	2400	51120	8120	0.403	121	114	1	1
100	103	150	150	38	1.1	149	347	1300	1800	51220M	8220	1.226	130	120	1	2.51
d 100～160mm
Overall Dimensions						Rated Load		Limiting Rotational Speed		Bearing Designation		Minimum Load A	Mounting Dimensions			Weight
d	d1min	D	D1max	H	rnin	Dynamic Load C	Static Load Co	Grease	Oil	Current Model	Original Model	Minimum Load A	da	Da	ramax	Weight
mm						kN		r/min					mm			kg
100	103	170	170	55	1.5	263	513	950	1400	51320M	8320	3.236	142	128	1.5	5.46
100	103	210	205	85	3	399	917	700	950	51420	8420	9.606	165	145	2.5	14.9
110	112	145	145	25	1	87.2	276	1600	2200	51122	8122	0.48	131	124	1	1.08
	113	160	160	38	1.1	139	393	1200	1700	51222	8222	1.58	140	130	1	2.6
	113	190	187	63	2	280	684	850	1200	51322	8322	4.216	158	142	2	7.9
	113	230	225	95	3	415	1150	630	850	51422	8422	12.7	181	159	2.5	20
120	122	155	155	25	1	87.1	295	1600	2200	51124	8124	0.48	141	134	1	1.16
	123	170	170	39	1.1	136	399	1200	1700	51224	8224	1.58	150	140	1	2.9
	123	210	205	70	2.1	330	869	800	1100	51324	8324	6.176	173	157	2	9.75
130	132	170	170	30	1	109	371	1400	1900	51126	8126	0.922	154	146	1	1.87
	133	190	187	45	1.5	186	535	950	1400	51226	8226	2.85	166	154	1.5	4.2
	134	225	220	75	2.1	358	1007	750	1000	51326	8326	7.36	186	169	2	13.3
	134	270	265	110	4	490	1520	560	750	51426	8426	26.3	213	187	3	32
140	142	180	178	31	1	111	380	1300	1800	51128	8128	0.99	164	156	1	2.1
	143	200	197	46	1.5	191	542	950	1400	51228	8228	3.15	176	164	1.5	4.5
	144	240	235	80	2.1	396	1159	700	950	51328	8328	10.4	199	181	2	15.9
	144	280	275	112	4	553	1750	500	700	51428	8428	26.3	222	198	3	32.2
150	152	190	188	31	1	112	380	1200	1700	51130	8130	1.09	174	166	1	2.2
	153	215	212	5	1.5	244	698	900	1300	51230	8230	4.13	189	176	1.5	5.8
	154	250	245	80	2.1	407	1226	670	900	51330	8330	12	209	191	2	16.7
160	162	200	198	31	1	112	404	1200	1700	51132	8132	1.276	184	176	1	2.3
	163	225	222	51	1.5	240	741	850	1200	51232	8232	4.52	199	186	1.5	6.7
	164	270	265	87	3	463	1425	630	850	51332	8332	16.3	225	205	2.5	21.5
