Ru Cross Roller Bearing Wholesale

1.Product Introduction: Supplying RU series crossed roller bearings in batches (the industry's common precision series), supporting customization, suitable for manufacturers' bulk purchases, including spot goods and customized services.
2.Wholesale Structure: Spot stocks of common specifications from RU80 to RU500 are available. For customization, orders start from 10 pieces (delivery period: 7 - 15 days). They are packaged with independent anti-rust packaging, accompanied by precision inspection reports, and support partial deliveries.
3.Conventional Wholesale Size Range: Outer ring diameter: 80 - 800mm (RU series standard size), inner ring diameter: 60 - 750mm, height: 15 - 60mm.
4.Material: Inner ring / outer ring: 50Mn, 42CrMo; rolling elements: GCr15 bearing steel, GCr15SiMn (optional for impact resistance); seals: nitrile rubber, fluororubber (optional for oil and high temperature resistance).
5.Application Fields: Precision machine tool manufacturers (bulk purchases), robot production enterprises, automated equipment manufacturers, medical device factories.
6.Key Inspection Items: Batch sampling for dimensional consistency, radial accuracy, no scratches or rust on the appearance.

Send Inquiry

Download

Product Description

Data Sheet

High-Precision Ru Cross Roller Bearing Wholesale for Heavy-Duty Industrial Applications – Customized & Delivered in 15–20 Days

30+ Years OEM Supplier of RU Cross Roller Bearings with P4-Grade Precision, 150°C High-Temperature Resistance, and IoT-Driven Lifecycle Support.

Why Choose Us?

If you're sourcing RU Cross Roller Bearing Wholesale options for robotics, medical imaging, or heavy machinery, you need a partner who combines precision engineering with rapid delivery. At LUOYANG INNO BEARING CO., LTD, we’ve delivered over 5 million cross roller bearings globally since 1993, specializing in both standard (OD: φ80–φ800mm) and custom designs up to φ5000mm. Our bearings maintain P4-grade radial accuracy even under 100kN loads, backed by ISO 9001 and industry-specific certifications like FDA and AS9100.

product-1440-1080

Product Overview

RU cross roller bearings excel in applications demanding high rigidity and compact designs. Unlike conventional bearings, their X-shaped roller arrangement distributes loads evenly, making them ideal for:

Medical Equipment: MRI scanner rotation systems requiring <35dB noise levels.
Industrial Robots: Articulated joints needing ±0.0025mm runout accuracy.
Port Cranes: Slewing mechanisms with 500°C thermal resistance.

product-1406-300

Key Parameters

Model	OD Range	Load Capacity	Precision Grade	Temperature Range
RU80	80–150mm	25kN/35kN	ABEC-7 (P4)	-30°C to +150°C
RU500	500–800mm	120kN/150kN	ABEC-7 (P4)	-60°C to +150°C

5 Reasons to Partner with Us for Your RU Bearing Needs

1. Material Mastery for Extreme Conditions

We use vacuum-degassed GCr15 steel (HRC 60-64 hardness) and fluorocarbon seals to withstand:

High Temperatures: 150°C stable operation via proprietary heat treatment.
Corrosive Environments: Salt spray resistance exceeding 720 hours (ASTM B117).
Heavy Impacts: Hybrid ceramic rollers available for shock loads up to 200kN.

2. Customization Without Compromise

Need a Ru Cross Roller Bearing Wholesale φ3000mm bearing with flange mounts? Our modular design system handles:

Non-Standard Sizes: Up to φ5000mm OD, delivered in 15–20 days.
Special Materials: Stainless steel (SUS440C) for medical sterilization.
Smart Features: Integrated IoT sensors for real-time wear monitoring.

3. Quality Built into Every Step

Our 3-stage QC process eliminates defects:

1. Material Checks: Spectral analysis to ensure ≤0.002% impurities.

2. In-Process Controls: Laser scanning for ±0.001mm dimensional accuracy.

3. Final Validation: 100% tested for vibration (ISO 15242-1) and noise.

4. Faster Delivery, Lower Inventory Costs

Standard Bearings: 1,000+ SKUs available in 48 hours.
Bulk Orders: MOQ 10 pieces for customs, partial shipments supported.
Regional Warehouses: Reduce lead times for EU, NA, and Asian clients.

5. Lifetime Support Beyond Delivery

Our engineers provide:

Predictive Maintenance: AI-driven alerts before bearing wear impacts operations.
Legacy Upgrades: Retrofit kits for older machinery needing modern precision.
24/7 Troubleshooting: On-call support for urgent breakdowns.

product-750-1000

FAQ

Q1: Can you match unique specs like φ3000mm OD or P4-grade precision?

Absolutely! 95% of non-standard requests are finalized within 72 hours using our modular design templates.

Q2: How do you ensure consistency in bulk orders?

Dedicated production lines with digital twin verification ensure ≤0.003mm batch-to-batch variation.

Q3: What certifications come with your RU Cross Roller Bearings?

All bearings include material test reports. Optional certifications: CE, FDA, AS9100, DNV-GL.

Q4: Do you offer discounts for 500+ piece orders?

Yes – contact us for volume pricing, especially for φ500-2000mm standard sizes.

Q5: Can I get CAD models for custom designs?

We provide STEP, IGES, and SolidWorks files within 24 hours of order confirmation.

Contact Us

Need a Reliable RU Cross Roller Bearing Wholesale Partner?

📧 Email engineers now: sales@inno-bearing.com

➤ Fast Response: Get technical specifications within 2 hours.

➤ Free Sample: Test a bearing in your application risk-free.

➤ Live Inventory Check: Confirm stock levels in real-time.

Optimize Your Bearing Performance Today!

Cross Cylindrical Roller Slewing Bearing-With External Teeth
D235～2500mm
Boundary Dimension			Bearing Type	Related Dimension												Gear Parameter					Weight
d	D	T		D1	d1	d2	H	h	DwP	n1	n2	n3	φ1	φ2	φ3	da	b	m	Z	X	kg≈
235	380	55	1797/235	358	259	308	45	8	308.5	2	27	24	ZG1/4	13	13	403.5	39	4.5	88	0	24
270	-	86	179254G2	456	300	386	81	5	387	3	9	9	ZG1/4	18	M16	520	80	8	63	0	70
400	-	80	1797/400	575	450	519	70	10	520	-	8	12	-	20	M20	656	80	8	80	0	108
545	867	132.5	LY-8013	805	611	693	12	10.5	695	4	35	40	G1/4	M27	30	920	90	10	90	0	290
574	781	90	111.25.675.03K/P6	753	604	675.5	71	16	677	3	18	18	M10X1	22	22	816	65	6	132	1.092	125
664	890	75	1797/664	847	705	774	65	10	776	4	35	36	M10X1	22	22	929.6	60	8	115	-0.4	133
608	812	75	111.25.710.12K	776	644	708.5	65	10	710	4	24	24	M10X1	18	M16	846	60	6	139	0	118
715	935	100	1797/715	893	753	821.5	84	16	823	4	28	28	M10X1	22	22	979	63	10	94	1.1	173
736	-	56	D1797/736G2	885	798	840	44.5	11.5	844	4	40	36	M10X1	1/2(美制）	1/2(美制）	944	44.5	4	234	0	80.9
678	922	82	111.28.800.12	878	722	798.5	72	10	800	6	30	30	M10X1	22	22	968	65	8	635	0.5	161
885	1056	83	1792/885	1032	925	986	75	12.5	987	-	16	16	-	17.5	M16	1096	62.5	8	135	0	172
885	1056	83	E1792/885	1032	925	986	75	12.5	987	-	16	16	-	17.5	M16	1096	62.5	8	135	0	172
885	1056	83	E1792/885K	1032	925	986	75	12.5	987	3	16	16	M10X1	17.5	M16	1096	62.5	8	135	0	172
885	1150	115	1797/885G	1115	935	1023	100	15	1025	4	16	16	M8X1	18	18	1180	80	5	234	0	330
1080	1475.5	110	112.36.1250.03	1350	1150	1248	100	21	1250	4	28	24	M10X1	M27	27	1475.5	75	10	144	0.86	542
1100	1400	140	1798/1100G2	1352	1160	1260	126	21	1262	4	26	26	M10X1	26	24	1477.28	90	14	104	-0.24	642
1100	1400	145	1798/1100G2K	1352	1160	1260	131	26	1262	4	26	26	M10X1	26	24	1477.28	90	14	104	-0.24	644
1100	1415	115	1797/1100G	1345	1160	1253	100	15	1254	4	18	24	M12X1.25	21	21	1452	84	6	240	0	502
1100	1400	140	1798/1100G2K1/P5	1352	1160	1260	119	14	1262	4	26	26	4	26	M22	1477.28	90	14	104	-0.24	651
1250	1548	148	1797/1250G2	1512	1297	1403	122	20	1405	4	16	16	M10X1	25	25	1608	100	12	132	0	661
1278	1595	120	1797/1278G2	1535	1335	1428	105	15	1430	4	36	36	M10X1	26	26	1655.46	90	12	134	1.15	597
1300	1705	165	1797/1300G	1644	1360	1504	134	31	1506	4	24	24	M10X1	32	32	1783.6	85	14	126	-0.3	1023
1400	1715	110	1792/1400G	1660	1460	1558	95	17	1560	4	42	42	M12X1.25	26	26	1780.8	78	12	147	-0.3	579
1400	1715	110	1792/1400G2	1660	1460	1558	95	17	1560	4	42	42	M12X1.25	26	26	1881.6	78	12	147	-0.3	579
1400	1715	110	1792/1400G2K	1660	1460	1558	95	17	1560	4	42	42	M12X1.25	26	26	1780.8	78	12	147	-0.3	579
1400	1715	110	E1792/1400G2K2	1660	1460	1558	95	17	1560	4	42	24	M12X1.25	没4	M24	1788	78	12	147	0	595
1400	1788	110	D1792/1400G2K1	1660	1460	1558	95	15	1560	4	24	24	M12X1.25	没4	M24	1788	78	12	147	0	585
1460	1800	125	1797/1460G2	1735	1525	1633	110	10	1635	4	24	32	M10X1	26	26	1881.6	95	14	133	-0.3	828
1460	-	125	1797/1460G2K	1735	1525	1633	110	10	1635	4	36	32	M10X1	26	26	1880	115	10	186	0	845
1460	1740	91	111.32.1600.04	1687	1513	1598	81	10	1600	5	36	45	M10X1	26	26	1820	75	14	127	0.5	486
1722	2020	123	1797/1722	1960	1780	1868	110	13	1870	12	45	36	M10X1	30	M27	2074	100	12	170	1	801
1785	2178	220	1797/1785	2110	1851	1977.5	210	20	1980	14	36	48	M10X1	33	33	2264.4	123	18	125	0.5	1941
1825	2178	112	111.40.2000.11	2110	1891	1998	100	12	1993	8	48	48	M10X1	33	33	2272	90	16	139	0.5	900
1914	-	190	1797/1914	2245	1980	2110	120	10	2112.5	14	48	42	M10X1	43	33	2444.4	180	18	133	1	2117
1915	2420	140	1797/1915G2	2320	1980	2113	130	20	1643	8	42	40	M10X1	34	34	2500	90	10	248	0	1643
1916	-	150	1797/1916G2	2245	1980	2113	130	15	2115	3	40	42	M10X1	34	34	2415.6	135	18	133	-0.4	1601
2100	2600	180	1797/2100G2	2540	2200	2368	158	22	2370	8	42	48	M10X1	32	32	2700	130	18	148	0	2395
2100	2600	180	1797/2100G2K	2540	2200	2368	158	22	2370	8	48	48	M10X1	32	32	2700	130	18	148	0	2392
2100	2600	180	1797/2100G2K1	2540	2200	2368	158	22	2370	8	48	48	M10X1	32	32	2700	130	18	148	0	2395
2100	2600	180	1797/2100G2K2	2540	2200	2368	158	22	2370	8	48	48	M10X1	32	32	2700	130	18	148	0	2395
2460	-	220	1797/2460G2	2930	2560	2785	185	20	2746	30	48	48	ZG1/4	34	33	3108	200	14	220	0	4091
2460	-	220	1797/2460G2K	2930	2560	2785	185	20	2746	15	30	30	M12X1.25	34	33	3108	200	14	220	0	4091
2460	-	220	1797/2460G2K1	2930	2560	2785	200	185	2746	30	30	30	ZG1/4	34	33	3108	200	14	220	0	4091
2460	-	220	1797/2460G2K2	2930	2560	2785	185	20	2746	30	30	30	ZG1/4	34	33	3108	200	14	220	0	4091
2460	-	220	1797/2460G2	2930	2560	2785	185	20	2746	30	30	30	ZG1/4	34	33	3108	200	14	220	0	4091
2500	2920	260	1797/2500K	3060	2622	2949	240	60	2820	36	30	36	M12X1.25	40	40	3258	190	18	179	0	5407
2500	2920	270	1797/2500K1	3060	2622	2949	250	60	2820	18	30	36	ZG1/4	40	40	3325	200	25	131	0	5450
2500	2920	260	1797/2500K2	3060	2622	2949	240	60	2820	18	30	36	ZG1/4	40	40	3258	190	18	179	0	5410
2500	-	210	1797/2500K3	2990	2630	2818	200	10	2820	12	30	36	M10X1	37	37	3250	200	25	128	0	4597
2500	2920	260	1797/2500K4	3060	2622	2949	240	60	2820	36	30	36	ZG1/4	40	40	3258	190	18	179	0	5410
2500	-	210	1797/2500K5	2990	2630	2818	200	10	2820	6	36	36	M16X1.5	37	37	3250	200	25	128	0	4632
2500	2920	260	1797/2500K6	3060	2622	2949	240	60	2820	36	36	36	ZG1/4	40	40	3258	190	18	179	0	5407
2500	-	210	1797/2500K7	3060	2622	2818	200	10	2820	12	36	36	ZG1/4	40	40	3258	200	18	179	0	4597
2500	-	210	1797/2500K8	2990	2630	2818	200	10	2820	12	36	36	ZG1/4	37	37	3250	200	25	128	0	4632
2500	2920	260	1797/2500K9	3060	2622	2949	240	60	2820	36	36	36	ZG1/4	40	40	3258	190	18	179	0	5556
2500	2920	260	1797/2500K10	3060	2622	2949	240	60	2820	36	36	36	ZG1/4	40	40	3258	190	18	179	0	5192
2500	2920	260	1797/2500K11	3060	2622	2949	240	60	2820	36	36	36	ZG1/4	40	40	3258	190	18	179	0	5557
2500	-	210	1797/2500G2	2990	2630	2818	200	10	2820	12	36	36	M14X1.5	37	37	3250	200	25	128	0	4597
2500	2920	260	1797/2500G2K1	3060	2622	2949	240	60	2820	36	36	36	ZG1/4	40	40	3258	190	18	179	0	5407
2500	2920	260	1797/2500G2K2	3060	2622	2949	240	60	2820	12	36	36	ZG1/4	40	40	3258	190	18	179	0	5407
2500	2920	260	1797/2500G2K3	3060	2622	2949	240	60	2820	36	36	36	ZG1/4	40	40	3258	190	18	179	0	5407
2500	-	210	1797/2500G2K5	2990	2630	2818	200	10	2820	6	36	36	M16X1.5	37	37	3250	200	25	128	0	4632
2500	-	210	1797/2500G2K6	2990	2630	2818	200	10	2820	12	36	36	M14X1.5	37	37	3250	200	25	128	0	4596
2600	-	200	1797/2600	3050	2700	2868	180	20	2870	12	60	60	ZG1/4	35	35	3232.8	180	20	160	-0.18	3558
2600	-	200	1797/2600G	3050	2700	2868	180	20	2870	6	60	60	M12X1.25	35	35	3232.8	180	20	160	-0.18	3936
2600	-	200	1797/2600G2	3050	2700	2868	180	20	2870	18	60	60	ZG1/4	35	35	3232.8	180	20	160	-0.18	3936
2600	-	200	1797/2600G2K	3050	2700	2868	180	20	2870	4	60	60	14	35	35	3232.8	180	20	160	-0.18	3936
2600	-	200	1797/2600G2K1	3050	2700	2868	180	20	2870	8	60	60	M10X1	35	35	3232.8	180	20	160	-0.18	3558
2600	-	200	1797/2600G2K3	3050	2700	2868	180	20	2870	12	60	60	ZG1/4	35	35	3232.8	180	20	160	-0.18	3558
2600	-	200	1797/2600G2K4	3050	2700	2868	180	20	2870	12	60	60	ZG1/4	35	35	3232.8	180	20	160	-0.18	3936
2600	-	200	1797/2600G2K5	3050	2700	2868	180	20	2870	18	60	60	ZG1/4	35	35	3232.8	180	20	160	-0.18	3936
2600	-	200	1797/2600G2K6	3050	2700	2868	180	20	2870	10	60	60	M10X1	35	35	3232.8	180	20	160	-0.18	3559
2625	2978	112	111.40.2800.03	2910	2691	2797.5	100	12	2800	8	56	56	M10X1	33	33	3078	90	18	168	0.5	1282
2625	2978	112	112.40.2800.12	2910	2691	2797	100	12	2800	8	56	56	M10X1	33	33	3078	90	20	151	0.5	1280
2625	-	150	112.40.2800.12K	2910	2691	2797	100	12	2800	8	56	56	10	33	33	3388	150	22	151	0.5	2780
2625	-	150	112.40.2800.12K1	2910	2691	2797	100	12	2800	8	56	56	10	35	35	3384	150	22	151	0.5	2780
2625	2978	144	112.40.2800.12K2	2910	2691	2797	132	12	2800	8	56	56	M10X1	33	33	3080	120	20	151	0.5	1741
2625	2978	144	112.40.2800.12K3	2910	2691	2797	132	12	2800	8	56	56	M10X1	33	33	3080	120	20	151	0.5	1741
2635	3332	270	1797/2635G	3240	2755	2998	240	45	3000	6	36	36	M12X1.25	42	42	3440	200	20	170	0	5973
2635	3332	270	1797/2635G2	3240	2755	2998	240	30	3000	12	36	36	ZG1/4	42	42	3440	200	20	170	0	5973
2635	3440	270	1797/2635	3240	2755	2998	225	45	3000	12	36	36	ZG1/4	42	42	3440	200	20	170	0	5925
2635	3440	270	1797/2635G2K	3240	2755	2998	225	45	3000	12	36	36	ZG1/4	42	42	3440	200	20	170	0	5925
2635	3440	270	1797/2635G2K1	3240	2755	2998	225	45	3000	9	36	36	ZG1/4	42	42	3440	200	20	170	0	5925
2800	3550	240	1797/2800G2	3390	2920	3152	220	20	3155	8	44	44	14	37	37	3680	200	23	158	0	5050
2922	3376	134	111.50.3150.12	3286	3014	3147.5	122	12	3150	8	56	56	M10X1	45	45	2476	110	20	171	0.5	2177
2922	3376	134	111.50.3150.12K	3286	3014	3147.5	122	12	3150	8	56	56	M10X1	45	45	3476	110	20	171	0.5	2177
2922	3376	134	112.50.3150.12	3286	3014	3147.5	122	12	3150	8	56	56	M14X1.5	45	45	3476	110	22	155	0.5	2177
2922	3376	134	112.80.3200.12K	3286	3014	3147.5	122	12	3150	8	56	56	6	45	45	3476	110	25	155	0.5	2177
2930	3470	210	112.80.3200.12K	3380	3020	3197	190	20	3200	8	48	48	M10X1	37	37	3600	180	25	142	0	4280
2930	3470	210	112.80.3200.12K1	3380	3020	3197	190	20	3200	8	48	48	ZG1/4	37	37	3600	180	25	142	0	4279
2930	3470	210	112.80.3200.03	3380	3020	3197	190	20	3200	8	48	48	6	37	37	3600	180	25	142	0	4279
2930	3470	210	112.80.3200.12K	3380	3020	3197	190	20	3200	8	48	48	6	37	37	3600	180	25	142	0	4279
3230	3970	240	1797/3230	3820	3350	3578	220	20	3580	9	54	52	M12X1.25	37	37	4100	200	25	162	0	7613
3230	3970	240	1797/3230G2	3820	3350	3578	220	20	3580	9	54	52	M12X1.25	37	37	4100	200	25	162	0	7613
3230	3970	240	1797/3230G	3820	3350	3578	220	20	3580	9	54	52	M12X1.25	37	37	4100	200	25	162	0	7612
3230	3970	240	1797/3230GY	3820	3380	3578	220	20	3580	4	36	52	M12X1.25	37	37	4100	200	25	162	0	7612
3230	3970	240	1797/3230G2K	3820	3350	3578	220	20	3580	8	54	52	14	37	37	4100	200	25	162	0	7613
3230	4092	240	1797/3230G2K2	3820	3350	3578	220	20	3580	9	54	52	M12X1.25	37	37	4092	200	25	184	0	7804
3230	4080	240	1797/3230G2K3	3820	3350	3578	220	20	3580	9	54	52	M12X1.25	37	37	4080	200	20	202	0	7302
3230	4100	240	1797/3230G2K4	3820	3350	3578	220	20	3580	8	54	52	ZG1/4	37	37	4100	200	25	162	0	7613
3230	4100	240	1797/3230G2K5	3820	3350	3578	220	20	3580	16	54	52	ZG1/4	37	37	4100	200	25	162	0	7612
3230	4100	240	1797/3230G2K6	3820	3380	3578	220	20	3580	4	36	52	M12X1.25	37	37	4100	220	25	162	0	7673
3230	3970	252	1797/3230G2K7	3820	3350	3578	220	32	3580	16	36	52	ZG1/4	37	37	4100	200	25	162	0	7870
3230	3970	240	1797/3230G2K8	3820	3350	3578	220	20	3580	10	54	52	M12X1.25	37	37	4100	200	25	162	0	7613
3230	3970	240	1797/3230G2K9	3820	3350	3578	220	20	3580	10	54	52	ZG1/4	37	37	4100	200	25	162	0	7663
3230	3970	240	1797/3230G2K10	3820	3350	3578	220	20	3580	8	54	52	M12X1.25	37	37	4100	200	25	162	1	7663
3230	3970	240	1797/3230G2K11	3820	3350	3578	220	20	3580	8	54	52	ZG1/4	37	37	4120	200	25	162	0.5	7663
3230	3970	240	1797/3230G2K13	3820	3350	3578	220	20	3580	13	54	52	14	37	37	4100	200	25	162	0.5	7613
3230	-	240	1797/3230Y3	3820	3380	3578	220	20	3580	13	36	52	ZG1/4	37	37	4100	220	25	162	0	7687
3230	-	240	1797/3230K4	3820	3380	3576	220	20	3580	18	67	52	M14X1.25	37	37	4100	200	25	162	0	7611
3230	4100	240	1797/3230K5	3820	3350	3578	220	20	3580	4	54	52	M12X1.25	37	37	4100	220	25	162	0	7673
3230	4100	240	1797/3230G2Y	3820	3380	3578	220	20	3580	4	36	52	M12X1.25	37	37	4100	200	25	162	0	7613
3230	4100	240	1797/3230G2Y2	3820	3380	3578	220	20	3580	4	36	52	M12X1.25	37	37	4100	200	25	162	0	7613
3230	4100	240	1797/3230G2Y3	3820	3380	3578	220	20	3580	4	36	52	M14X1.5	37	37	4100	220	25	162	0	7686
3230	4100	240	1797/3230G2Y4	3820	3380	3578	220	20	3580	9	36	52	M14X1.5	37	37	4100	220	25	162	0	7686
3230	4100	240	1797/3230GK4	3820	3380	3578	220	20	3580	18	69	52	M12X1.25	37	37	4100	200	25	162	0	7613
3230	4100	240	1797/3230GK5	3820	3350	3578	220	20	3580	4	54	52	M12X1.25	37	37	4100	200	25	162	0	7613
3230	4100	252	1797/3230GK6	3820	3350	3578	232	30	3580	8	54	52	M12X1.25	37	37	4100	200	25	162	0	7803
3230	4100	240	1797/3230G2Y3K	3820	3380	3578	220	20	3580	4	36	52	M12X1.25	37	37	4100	220	25	162	0	7686
3230	4100	240	1797/3230G2Y3K1	3820	3380	3578	220	20	3580	13	36	52	M14X1.5	39	39	4100	220	25	162	0	7673
3322	3776	134	111.52.3550.12	3686	3414	3548	122	12	3550	8	56	56	M10X1	45	45	3880	110	20	191	0.5	2464
3322	3776	134	111.52.3550.12K	3686	3414	3548	122	12	3550	8	56	56	M10X1	45	45	3880	110	20	191	0.5	2464
3322	3776	134	112.50.3550.03	3686	3414	3547.5	122	12	3550	8	56	56	M10X1	45	45	3894	110	22	174	0.5	2465
3322	3776	134	112.50.3550.12	3686	3414	3547	122	12	3550	8	56	56	6	45	45	3889.6	110	22	174	0.5	2465
3322	3776	134	112.50.3550.12K	3686	3414	3547	122	12	3550	8	56	56	M10X1	45	45	3889.6	110	22	174	0.5	2465
3322	3776	150	112.50.3550.12K1	3686	3414	3548	122	12	3550	8	56	56	M10X1	45	45	3894	150	22	174	0.5	2484
3760	4220	240	1797/3760G	4160	3840	3996	50	55	4000	4	48	48	M14X1.5	32	32	4326	135	14	307	0	4396
4014	4490	206	1797/4014	4411	4080	4243	30	30	4245.5	10	40	40	M10X1	30	30	4593	160	22	206	0.5	4812
4250	4940	250	1797/4250G	4840	4350	4598	25	25	4600	9	72	72	M16X1.5	48	48	5082	200	30	168	0	8954
4272	4726	174	112.50.4500.12K	4636	4364	4484	12	12	4487	10	30	30	RP1/4	33	33	4845	150	25	191	0.5	4366
